The MAX3232 device consists of two line drivers, two line receivers, and a dual charge-pump circuit with ±15-kV ESD protection terminal to terminal (serial-port connection terminals, including GND). The device meets the requirements of TIA/EIA-232-F and provides the electrical interface between an asynchronous communication controller and the serial-port connector. The charge pump and four small external capacitors allow operation from a single 3-V to 5.5-V supply. The devices operate at data signaling rates up to 250 kbit/s and a maximum of 30-V/µs driver output slew rate.
Sold out
MAX3232CDR
₹45.00
3- to 5.5-V dual channel 250kbps RS-232 line driver/receiver with +/-15-kV ESD protection
BRAND TEXAS INSTRUMENTS
max3232
Out of stock
Description
Reviews (0)
Shipping & Delivery
